ELEDF30PIR

DISCONTINUED - 30W LED floodlight with 120° PIR

OBSOLETED PRODUCT

Black | 30W | 4000K | 2550 lm | 25,000 hrs | IP54 | A+ Rated



icon-30w  icon-4000k  icon-2550lm  icon-25000hrs  icon-ip54  icon-aplus  icon-led  icon-120pir  icon-2year



ELEDF30PIR

OBSOLETED PRODUCT

Black | 30W | 4000K | 2550 lm | 25,000 hrs | IP54 | A+ Rated



icon-30w  icon-4000k  icon-2550lm  icon-25000hrs  icon-ip54  icon-aplus  icon-led  icon-120pir  icon-2year



SKU: 5013845048453 Category:
Categories: Obsoleted
SKU: 5013845048453
More Information
Features
  • Tempered glass diffuser
  • Aluminium construction
  • Pre-wired with 80cm cable
  • Vertically and horizontally adjustable PIR
  • Time on adjustment: 10 sec ± 3 sec – 10 min ± 3 min
  • 120° detection angle
  • Adjustable detection range between 5-9m
  • Lux level adjustments: 5 Lux ~ 2000 Lux
  • M.O.M: 1 / O.P.Q: 12
Specification
Lamp Specifications:
Luminaire lumens (with diffuser) 2550 lm
Lumens from chip (no diffuser) 3000 lm
Useful lumens 2400 lm
Rated Wattage 30W
Rated luminous flux 2400 lm
Nominal life time of the lamp 25,000 hrs
Colour temperature 4000K
Number of switching cycles before premature lamp failure 15,000
Warm-up time up to 60 % of the full light output Instant full light
Is this product dimmer compatible? No
Nominal beam angle 120°
Rated power wattage 30W
Rated lamp lifetime 25,000 hrs
Lamp power factor 0.9
Lumen maintenance factor at end of nominal life 70%
Starting time 0.5s
Colour rendering 80 Ra
Colour consistency Within a 6 step Macadam ellipse
Rated peak intensity 1400cd
Rated beam angle 120°
Voltage / Frequency 240V~50Hz
Lumens per watt Up to 85 lm / W
Weight (kg) 0.957
TSI Code 404094010
Not suitable for accent lighting
Downloads

You will need Adobe Acrobat Reader to access and print PDFs.

FAQ

What is the detection area?

120° – approximately 9m at an installation height of 2.5m

What adjustment controls are there?

Lux, time and sensitivity can be adjusted. The controls are on the rear of the sensor head.
