LEDLBAY50

50W linear LED luminaire

Black | 50W | 4000K | 6263 lm | 50,000 hrs | IP40



icon-50w  icon-4000k      icon-ip40  icon-led  icon-5year

LEDLBAY50

Black | 50W | 4000K | 6263 lm | 50,000 hrs | IP40



icon-50w  icon-4000k      icon-ip40  icon-led  icon-5year

SKU: 5013845050494 Categories: ,
Categories: High Bay & Low Bay
SKU: 5013845050494
More Information
Features

Not just a low bay!! Although suitable for use as low bay for warehouse lighting the aesthetic design also lends itself to installation in public areas. IES files available to enable lighting plans.

Comprehensive range of high performance fittings suitable for low level commercial retail and industrial applications.

PERFECT FOR COMMERCIAL, INDUSTRIAL & RETAIL APPLICATIONS

  • Frosted polycarbonate diffuser
  • Aluminum housing
  • Suspension pack included, max length 1.5m
  • Brackets available separately (see LBB range) for surface mounting or to enable installation with threaded rod
  • Fitted with 1.5m mains input cable
  • M.O.M: 1 / O.P.Q: 8
Specification
Lamp Specifications:
Luminaire lumens (with diffuser) 6263 lm
Lumens from chip (no diffuser) 6601 lm
Useful lumens 5950 lm
Rated Wattage 50W
Rated luminous flux 5950 lm
Nominal life time of the lamp 50,000 hrs
Colour temperature 4000K
Number of switching cycles before premature lamp failure >15,000
Warm-up time up to 60 % of the full light output Instant full light
Is this product dimmer compatible? No
Nominal beam angle 120°
Rated power wattage 50W
Rated lamp lifetime 50,000 hrs
Displacement factor ≥0.9
Lumen maintenance factor at end of nominal life ≥0.8
Starting time Instant Full Light
Colour rendering >80 Ra
Colour consistency Within a 6 step Macadam ellipse
Rated peak intensity 2289cd
Rated beam angle 120°
Voltage / Frequency 240V~50Hz
Lumens per watt 119 lm / W
This luminaire contains a light source of class E
Not suitable for accent lighting
