CHA18MW

Chara Range - Power and colour temperature selectable circular LED ceiling/wall light with MW sensor

Chara Range

White | 9/14/18W | 3000/4400/6500K | 1000-2130 lm | 40,000 hrs | IP65 | IK10



             icon-led

CHA18MW

Chara Range

White | 9/14/18W | 3000/4400/6500K | 1000-2130 lm | 40,000 hrs | IP65 | IK10



             icon-led

Categories: Ceiling/Wall/Bulkheads
SKU: 5013845058995
More Information
Features

Offering 3 selectable power levels and 3 selectable colour temperatures, this versatile range offers the ultimate in practicality and multiple options from a single product. Suitable for interior or exterior installation the range of accessories ensures suitability for functional or decorative applications.

  • All fittings come with a white full trim
  • Optional accessories available separately
  • Power Selectable – options of 9W, 14W and 18W easily set by a dip switch on the driver
  • Colour temperature selectable – options of 3000K, 4400K & 6500K easily set by a dip switch on the driver
  • Hinged LED array
  • Push fit terminal block
  • Polycarbonate diffuser
  • Enclosure rated as IK10 for impact resistance
  • Central BESA box mounting option on the base
  • M.O.M: 1 / O.P.Q: 10
  • Standard On/Off Microwave Sensor Versions:
  • Adjustable detection angle: up to 150°
  • Adjustable detection range: Max. 4-6m at 3m installation height
  • Adjustable time setting: 5 seconds – 30 minutes
  • Adjustable Lux control: 2/10/25/50 lux or disable
  • Detection is possible through doors, glass panels & thin walls
Specification
Lamp Specifications:
9W 14W 18W
Luminaire lumens (with diffuser) 3000K – 1000 lm
4400K – 1100 lm
6500K – 1100 lm
3000K – 1500 lm
4400K – 1670 lm
6500K – 1640 lm
3000K – 1880 lm
4400K – 2130 lm
6500K – 2050 lm
Lumens from chip (no diffuser) 3000K – 1120 lm
4400K – 1220 lm
6500K – 1230 lm
3000K – 1680 lm
4400K – 1880 lm
6500K – 1850 lm
3000K – 2120 lm
4400K – 2400 lm
6500K – 2320 lm
Useful lumens 3000K – 900 lm
4400K – 1000 lm
6500K – 1000 lm
3000K – 1350 lm
4400K – 1500 lm
6500K – 1480 lm
3000K – 1700 lm
4400K – 1900 lm
6500K – 1860 lm
Rated Wattage 9W 14W 18W
Rated luminous flux 3000K – 900 lm
4400K – 1000 lm
6500K – 1000 lm
3000K – 1350 lm
4400K – 1500 lm
6500K – 1480 lm
3000K – 1700 lm
4400K – 1900 lm
6500K – 1860 lm
Nominal life time of the lamp 40,000 hrs 40,000 hrs 40,000 hrs
Colour temperature 3000/4400/6500K 3000/4400/6500K 3000/4400/6500K
Number of switching cycles before premature lamp failure 15000 15000 15000
Warm-up time up to 60 % of the full light output Instant full light Instant full light Instant full light
Is this product dimmer compatible? No No No
Nominal beam angle 120° 120° 120°
Rated power wattage 9W 14W 18W
Rated lamp lifetime 40,000 hrs 40,000 hrs 40,000 hrs
Lamp power factor >0.75 >0.75 >0.75
Lumen maintenance factor at end of nominal life ≥80 ≥80 ≥80
Starting time Instant full light Instant full light Instant full light
Colour rendering ≥80 ≥80 ≥80
Colour consistency Within a 6 step Macadam ellipse Within a 6 step Macadam ellipse Within a 6 step Macadam ellipse
Rated peak intensity 3000K – 286cd
4400K – 310cd
6500K – 312cd
3000K – 432cd
4400K – 484cd
6500K – 746cd
3000K – 611cd
4400K – 621cd
6500K – 605cd
Rated beam angle 120° 120° 120°
Voltage / Frequency 240V~50-60Hz 240V~50-60Hz 240V~50-60Hz
Lumen efficacy 3000K – 111 lm / W
4400K – 122 lm / W
6500K – 122 lm / W
3000K – 107 lm / W
4400K – 119 lm / W
6500K – 117 lm / W
3000K – 104 lm / W
4400K – 118 lm / W
6500K – 114 lm / W
Earthed
Not suitable for accent lighting
