D130
DISCONTINUED - 28W 2D slim profile low energy fitting
OBSOLETED PRODUCT
White | 28W | 3500K | 2256 lm | 8,000 hrs | IP20 | A Rated | Lamp Included
D130
OBSOLETED PRODUCT
White | 28W | 3500K | 2256 lm | 8,000 hrs | IP20 | A Rated | Lamp Included
Features
- D130 requires 1 x 28W GR10q 4 pin DD CFL (included). Fitting is rated at 28W max
- This luminaire is compatible with bulbs of the energy classes: A to E and is sold with a bulb of the energy class: A
- High frequency electronic ballast: instant start, flicker free operation, and prolonged lamp life
- Concealed diffuser clips
- Pressed steel base
- Acrylic diffuser
- Slim profile
- M.O.M: 1 / O.P.Q: 6
Specification
| Lamp Specifications: | |
|---|---|
| Nominal Wattage | 28W |
| Rated Wattage | 28W |
| Average lifetime hours | 8,000 hrs |
| Nominal useful luminous flux | 2256 lm |
| Rated luminous flux | 2256 lm |
| Luminous efficacy (Lm/W) in 50Hz operation | 80 |
| Rated lamp Lumen maintenance | 2000hrs: 85% 4000 hrs: 78% 8000 hrs: 75% |
| Rated survival factors | 2000hrs: 98% 4000 hrs: 90% 8000 hrs: 50% |
| Lamp dimensions | 200x200mm |
| Cap type | GR10q 4 Pin |
| Lamp Mercury content to an accuracy of 0.1mg | ≤2.5mg |
| Colour rendering index Ra | 84.2 |
| Colour temperature | 3500K |
| Ambient temperature required to achieve maximum luminous flux | 25°C |
| Is this product dimmer compatible? | No |
| Ballast EEI | A2 |
