DD16235

DISCONTINUED - 16W GR8 2 pin DD CFLni lamp

OBSOLETED PRODUCT

16W | 3500K | 1100 lm | 10,000 hrs | A Rated | GR8 2 Pin



icon-16w  icon-3500k  icon-1100lm  icon-10000hrs  icon-arated  icon-GR8-2-Pin

DD16235

OBSOLETED PRODUCT

16W | 3500K | 1100 lm | 10,000 hrs | A Rated | GR8 2 Pin



icon-16w  icon-3500k  icon-1100lm  icon-10000hrs  icon-arated  icon-GR8-2-Pin

SKU: 5013845031158 Category:
Categories: Obsoleted
SKU: 5013845031158
More Information
Features

Standard size energy efficient compact fluorescent lamp used in many commercial & decorative luminaires.

  • M.O.M: 10 / O.P.Q: 10
Specification
Lamp Specifications:
Nominal Wattage 16W
Rated Wattage 16W
Average lifetime hours 10,000 hrs
Nominal useful luminous flux 1100 lm
Rated luminous flux 1100 lm
Luminous efficacy (Lm/W) in 50Hz operation 68
Rated lamp Lumen maintenance 2000hrs: ≥85%
4000 hrs: ≥78%
6000 hrs: ≥76%
8000 hrs: ≥75%
Rated survival factors 2000hrs: ≥98%
4000 hrs: ≥90%
6000 hrs: ≥88%
8000 hrs: ≥80%
Lamp dimensions 136x133x26mm
Cap type GR8 2 Pin
Lamp Mercury content to an accuracy of 0.1mg ≤3.5mg
Colour rendering index Ra ≥80
Colour temperature 3500K
Ambient temperature required to achieve maximum luminous flux 25°C
Is this product dimmer compatible? No
Lumens per watt Up to 68 lm / W
Weight (kg) 0.121
TSI Code 394778637
