Lina. Black
E02LNACB Lina Power and CCT Switchable IP66 Circular Bulkhead Black
The Lina is a IP66 amenity bulkhead that offers flexibility with 3 adjustable wattages and 5 colour temperatures. The Lina can suit both residential or commercial settings including perimeter lighting, paths, gardens, and staircases. Compatible with the PlugPlack emergency and microwave sensors enabling further flexibility to suit different requirements on site.
- Power selectable 8W, 14W, 16W
- Colour temperature selectable 2700K, 3000K, 4000K, 5000K, 6000K
- IK08 IP66 rated
- Central integrated emergency LED array
- Fastened opal polycarbonate diffuser with a twist on trim
- Hinged LED tray
- Two 20mm rear cable entries and central mounted BESA point
- Loop in, loop out push fit terminals
- Compatible with PlugPack sensors and emergency module
- 5 year warranty
SPECIFICATION
-
+
| Light Source | LED |
| Finish | Black |
| Construction Materials | Polycarbonate |
| Construction Materials 2 | ABS |
| Nominal Voltage | 240 |
| Wattage | 8W / 14W / 16W |
| Colour Temperature | 2700K / 3000K / 4000K / 5000K / 6000K |
| Beam Angle | 120 |
| Lumens | 1000 - 1900 lm |
| LMW | 125 - 119 lm/w |
| CRI | 80 |
| IP/IK Rating | IP66 / IK08 |
| Average Rated Life | 50,000 |
| Product Warranty | 5 Years |
