EBLSLIMM

Slim LED maintained emergency exit box

White | 5.2W | 6000K | 80 lm | 30,000 hrs | IP20



icon-5-2w  icon-6000k  icon-80lm  icon-30000hrs  icon-ip20  icon-led  icon-emergency  icon-5year

EBLSLIMM

White | 5.2W | 6000K | 80 lm | 30,000 hrs | IP20



icon-5-2w  icon-6000k  icon-80lm  icon-30000hrs  icon-ip20  icon-led  icon-emergency  icon-5year

SKU: 5013845040273 Categories: ,
Categories: Emergency Lighting
SKU: 5013845040273
More Information
Features

An aesthetically pleasing, low energy, ultra slim alternative to conventional exit boxes

Slimmer and more discrete exit box, but still offering long term performance and reliability.

PERFECT FOR OFFICE, COMMERCIAL AND INDUSTRIAL APPLICATIONS

Battery replacement service available. Click HERE for details.

  • Ultra slim design: excellent solution where a more compact fitting is required
  • 3 hour maintained mode as standard which can also be configured for non maintained operation
  • Diffuser on base: for added downward illumination of exit path
  • Interchangeable up, down, left & right arrow exit legends included
  • Long life energy efficient LED light source eliminates lamp replacement cycle without compromising panel visibility distance
  • Facility for remote switching
  • LED charge light
  • For wall mounting only
  • Viewing distance 33m
  • Battery – Ni-Mh 3.6V 2000mAh
  • Battery 1 year warranty – Replacement battery code: EB7
  • M.O.M: 1 / O.P.Q: 10
Specification
Lamp Specifications:
Lumens 80 lm
Rated Wattage 5.2W
Nominal life time of the lamp 30,000 hrs
Colour temperature 6000K
Viewing distance 34M
Voltage 220-240V
Lumens per watt Up to 15 lm / W
Weight (kg) 0.922
TSI Code 397934326
Downloads

You will need Adobe Acrobat Reader to access and print PDFs.

FAQ

What is the viewing distance of the exit sign?

34m

Can this be converted to non-maintained?

Yes, by removing the link wire between L and L1 terminals
