EX360PIRWH

IP44 external 360° PIR detector

White | IP44



icon-ip44

EX360PIRWH

White | IP44



icon-ip44

SKU: 5013845008631 Category:
Categories: Lighting Controls & Accessories
SKU: 5013845008631
More Information
Features
  • ABS construction
  • Vertically & horizontally adjustable PIR head
  • Bracket included for optional corner mounting: versatile installation options to suit a wide range of requirements
  • Adjustable lux level
  • 1000W incandescent lamp / 300W fluorescent / 150W LED (no more than eight lights) load capacity
  • Time on adjustable: 5 sec – 5 min
  • 12 metre detection area
  • 360º detection zone
  • M.O.M: 1 / O.P.Q: 20
Specification
Weight (kg) 0.313
TSI Code 390010645
Downloads

You will need Adobe Acrobat Reader to access and print PDFs.

FAQ

Is there a troubleshooting guide?

Yes – for troubleshooting guide please refer to the installation instructions (found in the download tab)

Does EX360PIRWH have a minimum load?

No

Will EX360PIRWH switch LEDs?

Yes

What is the maximum load?

1000W incandescent
300W fluorescent
150W LED (maximum eight lights)

Can multiple EX360PIRWH be linked to control the same load?

We do not recommend using more than one PIR to control the same load

What adjustment controls are there?

Lux and time can be adjusted. The controls can be accessed by tilting the head of the sensor as detailed in the install guide (found in the download tab)

What is the detection area?

The detection area is approximately 12m when mounted at 2.5m-3m height
