KBLPAN
36W 4000K 600x600mm backlit LED panel
White | 36W | 4000K | 4000 lm | 40,000 hrs
KBLPAN
White | 36W | 4000K | 4000 lm | 40,000 hrs
Features
This commercial backlit LED panel produces a uniform light output with easy loop-in, loop-out push fit connectors whilst maintaining an ultra thin 35mm depth.
- Steel back panel, aluminium frame and polystyrene diffuser construction
- Zero maintenance, integral light source providing instant light output
- Operating temperature: 5 to 45°C
- Lumen efficacy: 111 lm / W
- Includes a plug and play constant current non-dimmable LED driver
- Ra: ≥80, high CRI to minimise colour distortion of illuminated products in retail applications
- White trim finish to match the majority of T. bar ceilings
- Push fit wiring terminal direct into the LED driver
- Surface mounting can be achieved by using screwless kit: SURFACEMK
- Can be recessed in the ceiling or suspended from wires: see PANSUSKIT suspension kit
- Ability to be converted into an emergency luminaire: see EBPM3 / SEEBPM3 / EBPM3LI
- M.O.M: 1 / O.P.Q: 6
Specification
| Lamp Specifications: | |
|---|---|
| Luminaire lumens (with diffuser) | 4000 lm |
| Lumens from chip (no diffuser) | 4500 lm |
| Useful lumens | 3600 lm |
| Rated Wattage | 36W |
| Rated luminous flux – Warm White, Cool White, Daylight White | 3600 lm |
| Nominal life time of the lamp | 40,000 hrs |
| Colour temperature | 4200K |
| Number of switching cycles before premature lamp failure | ≥15,000 |
| Warm-up time up to 60 % of the full light output | Instant Full Light |
| Is this product dimmer compatible? | No |
| Nominal beam angle | 120° |
| Rated power wattage | 36W |
| Rated lamp lifetime | 40,000 hrs |
| Lamp power factor | ≥0.9 |
| Lumen maintenance factor at end of nominal life | ≥80 |
| Starting time | Instant Full Light |
| Colour rendering | ≥80 Ra |
| Colour consistency | Within a 6 step Macadam ellipse |
| Rated peak intensity | 1177cd |
| Rated beam angle | 120° |
| Voltage / Frequency | 240V~50Hz |
| Lumen efficacy | 111 lm / W |
| Class 2 double insulated | |
| Not suitable for accent lighting | |
