KCAS14BKLV
Cassi Range - IP54 14W circular LED ceiling/wall light with louvered trim
CASSI Circular Range
Black | 14W | 4000K | 1480 lm | 30,000 hrs | IP54 | IK08
KCAS14BKLV
CASSI Circular Range
Black | 14W | 4000K | 1480 lm | 30,000 hrs | IP54 | IK08
Features
- Stainless Steel captive fixing screws
- Polycarbonate diffuser
- 20mm cable entry on back of fitting
- Push fit terminal block
- M.O.M: 1 / O.P.Q: 20
Specification
| Lamp Specifications: | |
|---|---|
| Luminaire lumens (with diffuser) | 1310 lm |
| Lumens from chip (no diffuser) | 1560 lm |
| Useful lumens | 1250 lm |
| Rated Wattage | 14W |
| Rated luminous flux | 1250 lm |
| Nominal life time of the lamp | 30,000 hrs |
| Colour temperature | 4000K |
| Number of switching cycles before premature lamp failure | ≥15,000 |
| Warm-up time up to 60% of the full light output | <1s |
| Is this product dimmer compatible? | No |
| Nominal beam angle | 120° |
| Rated power wattage | 14W |
| Rated lamp lifetime | 30,000 hrs |
| Lamp power factor | >0.55 |
| Lumen maintenance factor at end of nominal life | ≥0.45 |
| Starting time | <0.1s |
| Colour rendering | ≥80 |
| Colour consistency | Within a 6 step Macadam ellipse |
| Rated peak intensity | 420cd |
| Rated beam angle | 120° |
| Voltage / Frequency | 240V~50Hz |
| Lumen efficacy | 93.5 lm / W |
| Not suitable for accent lighting | |
