LBAT5FTEM3

5FT emergency LED batten

White | 38W | 4200K | 4800 lm | 35,000 hrs | IP20 | A++ Rated



           icon-emergency  icon-led  icon-5year



LBAT5FTEM3

White | 38W | 4200K | 4800 lm | 35,000 hrs | IP20 | A++ Rated



           icon-emergency  icon-led  icon-5year



SKU: 5013845050319 Categories: ,
Categories: Battens, EternaPro
SKU: 5013845050319
More Information
Features

Full photometric data available to enable lighting designs. Light output is equivalent or superior to traditional fluorescent battens.

High Performance battens – perfect for new installs & replacing fluorescent.

PERFECT FOR OFFICE, COMMERCIAL & EDUCATIONAL APPLICATIONS

Battery replacement service available. Click HERE for details.

  • Pressed steel body and polycarbonate diffuser
  • LED tray can be removed from the housing for easy installation
  • 20mm knockout glands at each end for through wiring options
  • BESA box mounting
  • Gear tray retaining straps
  • Push terminal connections
  • Replacement battery code: EB2
  • EMERGENCY VERSION (WITH LDLEM3):
  • Pre-wired for easy installation
  • LED glows green in standby mode and super bright white light in the event of a mains failure
  • Minimum 3 hour functionality in emergency mode
  • 118 lumens in emergency mode
  • M.O.M: 1 / O.P.Q: 6
Specification
Lamp Specifications:
Luminaire lumens (with diffuser) 4800 lm
Lumens from chip (no diffuser) 5100 lm
Useful lumens 4600 lm
Rated Wattage 38W
Rated luminous flux 4600 lm
Nominal life time of the lamp 35,000 hrs
Colour temperature 4200K
Number of switching cycles before premature lamp failure >15,000
Warm-up time up to 60 % of the full light output Instant full light
Is this product dimmer compatible? No
Nominal beam angle 120°
Rated power wattage 38W
Rated lamp lifetime 35,000 hrs
Lamp power factor >0.9
Lumen maintenance factor at end of nominal life >0.70
Starting time <0.1s
Colour rendering >80 Ra
Colour consistency Within a 6 step Macadam ellipse
Rated peak intensity 1333cd
Rated beam angle 120°
Voltage / Frequency 240V~50Hz
Lumens per watt Up to 126 lm / W
Weight (kg) 2.243
TSI Code 404495868
Not suitable for accent lighting
