OF16PR

DISCONTINUED - 16W 2D circular prismatic IP65 ceiling/wall fitting

OBSOLETED PRODUCT

Prismatic | 16W | 3500K | 1100 lm | 10,000 hrs | IP65 | A Rated | Lamp Included



icon-16w  icon-3500k  icon-1100lm  icon-10000hrs  icon-ip65  icon-arated

OF16PR

OBSOLETED PRODUCT

Prismatic | 16W | 3500K | 1100 lm | 10,000 hrs | IP65 | A Rated | Lamp Included



icon-16w  icon-3500k  icon-1100lm  icon-10000hrs  icon-ip65  icon-arated

SKU: 5013845038256 Category:
Categories: Obsoleted
SKU: 5013845038256
More Information
Features
  • 16W requires 1 x 16W GR10q 4pin DD CFL (included). Fitting is rated at 16W max
  • This luminaire is compatible with bulbs of the energy classes: A to E and is sold with a bulb of the energy class: A
  • Ceiling or wall mounted: versatile fixing options
  • Removable metal gear tray: easy installation and maintenance
  • High frequency electronic ballast: instant start, flicker free operation, and prolonged lamp life
  • Polycarbonate construction
  • M.O.M: 1 / O.P.Q: 8
Specification
Lamp Specifications:
Nominal Wattage 16W
Rated Wattage 16W
Average lifetime hours 10,000 hrs
Nominal useful luminous flux 1100 lm
Rated luminous flux 1100 lm
Luminous efficacy (Lm/W) in 50Hz operation 68
Rated lamp Lumen maintenance 2000hrs: ≥85%
4000 hrs: ≥78%
6000 hrs: ≥76%
8000 hrs: ≥75%
Rated survival factors 2000hrs: ≥98%
4000 hrs: ≥90%
6000 hrs: ≥88%
8000 hrs: ≥80%
Lamp dimensions (H/W/D) 136x133x26mm
Cap type GR10q 4 Pin
Lamp Mercury content to an accuracy of 0.1mg ≤3.5mg
Colour rendering index Ra ≥80
Colour temperature 3500K
Ambient temperature required to achieve maximum luminous flux 25°C
Is this product dimmer compatible? No
Ballast EEI A2
Lumens per watt
Weight (kg) 0.869
TSI Code 396975700
