Fresh Prince - circular LED power + colour temperature selectable fitting with prismatic diffuser

Fresh Prince Range

Circular | Prismatic | 9/14/18W | 3000/4400/6500K | 1180-2270lm | 50,000 hrs | IP65 | IK10



    icon-ip65    icon-led  icon-5year

PRCIRSTD

Fresh Prince Range

Circular | Prismatic | 9/14/18W | 3000/4400/6500K | 1180-2270lm | 50,000 hrs | IP65 | IK10



    icon-ip65    icon-led  icon-5year

Categories: Ceiling/Wall/Bulkheads
SKU: 5013845059459
More Information
Features

High output, energy saving utility LED wall / ceiling fixtures with standard, emergency & multi-function microwave control versions. Both opal & clear versions are available for either smooth diffused effect or maximum light output. Diffusers are supplied not fitted to bases and fully captive diffuser fixing screws are utilised to save installation time. Step Dim microwave versions provide the best in flexibility & energy saving options.

  • Polycarbonate construction
  • Push fit terminals
  • Hinged gear tray
  • Captive fixing screws
  • Four 20mm cable entries on the side and one to the rear
  • Central BESA box mounting option on the base
  • Power Selectable – options of 9W, 14W and 18W easily set by a dip switch on the driver
  • Colour temperature selectable – options of 3000K, 4400K & 6500K easily set by a dip switch on the driver
  • 5 year warranty
  • M.O.M: 1 / O.P.Q: 8
Specification
Circular Prismatic LED Specifications:
9W 14W 18W
Luminaire lumens (with diffuser) 3000K – 1180 lm
4400K – 1270 lm
6500K – 1230 lm
3000K – 1715 lm
4400K – 1890 lm
6500K – 1780 lm
3000K – 2055 lm
4400K – 2270 lm
6500K – 2180 lm
Lumens from chip (no diffuser) 3000K – 1220 lm
4400K – 1300 lm
6500K – 1265 lm
3000K – 1810 lm
4400K – 1990 lm
6500K – 1890 lm
3000K – 2210 lm
4400K – 2460 lm
6500K – 2350 lm
Useful lumens 3000K – 1140 lm
4400K – 1225 lm
6500K – 1190 lm
3000K – 1630 lm
4400K – 1790 lm
6500K – 1690 lm
3000K – 1950 lm
4400K – 2160 lm
6500K – 2070 lm
Rated Wattage 9W 14W 18W
Rated luminous flux 3000K – 1140 lm
4400K – 1225 lm
6500K – 1190 lm
3000K – 1630 lm
4400K – 1790 lm
6500K – 1690 lm
3000K – 1950 lm
4400K – 2160 lm
6500K – 2070 lm
Nominal life time of the lamp 50,000 hrs 50,000 hrs 50,000 hrs
Colour temperature 3000/4400/6500K 3000/4400/6500K 3000/4400/6500K
Number of switching cycles before premature lamp failure ≥15000 ≥15000 ≥15000
Warm-up time up to 60% of the full light output Instant full light Instant full light Instant full light
Is this product dimmer compatible? No No No
Nominal beam angle 120° 120° 120°
Rated power wattage 9W 14W 18W
Rated lamp lifetime 50,000 hrs 50,000 hrs 50,000 hrs
Displacement factor 0.97 0.97 0.97
Lumen maintenance factor at end of nominal life ≥80 ≥80 ≥80
Starting time Instant full light Instant full light Instant full light
Colour rendering ≥0.8 ≥0.8 ≥0.8
Colour consistency Within a 6 step Macadam ellipse Within a 6 step Macadam ellipse Within a 6 step Macadam ellipse
Rated peak intensity 3000K – 398cd
4400K – 428cd
6500K – 415cd
3000K – 570cd
4400K – 627cd
6500K – 592cd
3000K – 683cd
4400K – 754cd
6500K – 722cd
Rated beam angle 120° 120° 120°
Voltage / Frequency 220-240V~50Hz 220-240V~50Hz 220-240V~50Hz
Lumen efficacy 3000K – 131 lm / W
4400K – 141 lm / W
6500K – 137 lm / W
3000K – 122 lm / W
4400K – 135 lm / W
6500K – 127 lm / W
3000K – 114 lm / W
4400K – 126 lm / W
6500K – 121 lm / W
This product contains a Light Source of Energy Efficiency Class F
Class 2 double insulated
Not suitable for accent lighting
