RDL12
DISCONTINUED - 12.7W recessed LED downlight
OBSOLETED PRODUCT
White | 12.7W | 4000K | 1010 lm | 25,000 hrs | A+ Rated
RDL12
OBSOLETED PRODUCT
White | 12.7W | 4000K | 1010 lm | 25,000 hrs | A+ Rated
Features
Long life, energy efficient alternative to low energy fluorescent downlights.
Hole cut out size: 160-164mm
PERFECT FOR OFFICE & COMMERCIAL APPLICATIONS
- Polycarbonate construction
- Multiple low power LED array: even, shadow free diffused light output
- Instant start to full illumination
- Unobtrusive design with neutral white trim
- 4000K colour temperature: for neutral white appearance
- Compatible with emergency battery pack
- M.O.M: 1 / O.P.Q: 10
Specification
| Lamp Specifications: | |
|---|---|
| Lumens total flux | 1010 lm |
| Lumens from chip | 1200 lm |
| Rated Wattage | 12.7W |
| Rated luminous flux | 1010 lm |
| Nominal life time of the lamp | 25,000 hrs |
| Colour temperature | 4000K |
| Number of switching cycles before premature lamp failure | 15,000 |
| Warm-up time up to 60 % of the full light output | Instant full light |
| Is this product dimmer compatible? | No |
| Nominal beam angle | >120° |
| Rated power wattage | 12.7W |
| Rated lamp lifetime | 25,000 hrs |
| Lamp power factor | >0.9 |
| Lumen maintenance factor at end of nominal life | 70% |
| Starting time | 0.1s |
| Colour rendering | >80 Ra |
| Colour consistency | Within a 6 step Macadam ellipse |
| Rated peak intensity | 355cd |
| Rated beam angle | >120° |
| Voltage | 240V |
| Not suitable for accent lighting | |
