TAB10PIRBK

DISCONTINUED - 10W tablet LED floodlight with 120° PIR

OBSOLETED PRODUCT

Black | 10W | 4000K | 750 lm | 30,000 hrs | IP44 | A+ Rated



icon-10w  icon-4000k  icon-750lm  icon-30000hrs  icon-ip44  icon-aplus  icon-led  icon-120pir  icon-2year



TAB10PIRBK

OBSOLETED PRODUCT

Black | 10W | 4000K | 750 lm | 30,000 hrs | IP44 | A+ Rated



icon-10w  icon-4000k  icon-750lm  icon-30000hrs  icon-ip44  icon-aplus  icon-led  icon-120pir  icon-2year



SKU: 5013845045650 Category:
Categories: Obsoleted
SKU: 5013845045650
More Information
Features

Super slim, aesthetically pleasing LED floodlight with black & white, PIR and non PIR versions available

  • Aluminium & polycarbonate construction
  • Mains voltage LED chips – no driver required
  • Quick fix bracket allowing fixing without removing bracket from fixture
  • Pre-wired with 80cm flex
  • Vertically and horizontally adjustable PIR
  • Time on adjustment: 10 sec ± 2 sec – 7 min ± 2 min
  • 120° detection angle, detection range 2 – 7 metres
  • Lux level adjustments: 2 Lux ~ 2000 Lux
  • M.O.M: 1 / O.P.Q: 20
Specification
Lamp Specifications:
Lumens total flux 750 lm
Rated Wattage 10W
Nominal life time of the lamp 30,000 hrs
Colour temperature 4000K
Number of switching cycles before premature lamp failure 15,000
Warm-up time up to 60 % of the full light output Instant full light
Is this product dimmer compatible? No
Nominal beam angle 120°
Rated power wattage 10W
Rated lamp lifetime 30,000 hrs
Lamp power factor >0.5
Lumen maintenance factor at end of nominal life 70%
Starting time <0.5s
Colour rendering >80 Ra
Colour consistency Within a 6 step Macadam ellipse
Rated peak intensity 231.45cd
Rated beam angle 120°
Voltage 240V
Not suitable for accent lighting
