TLS1440

Electronic time delay push switch

White | 1440W Max | IP20



icon-1440w  icon-ip20

TLS1440

White | 1440W Max | IP20



icon-1440w  icon-ip20

SKU: 5013845022255 Categories: ,
Categories: Lighting Controls
SKU: 5013845022255
More Information
Features
  • ABS construction
  • Time on adjustable between 12 seconds and 12 minutes
  • No neutral connection required: can replace existing switch with no additional wiring
  • Red neon switch perimeter glow light: easy location of switching point
  • Max load rating: 6 Amp incandescent 1440W
  • NOT COMPATIBLE WITH LED – SEE PUSHLED
  • M.O.M: 5 / O.P.Q: 40
Downloads

You will need Adobe Acrobat Reader to access and print PDFs.

FAQ

What is the minimum load for this fitting?

5 Watt

What is the maximum load?

6A, for incandescent this is approximately 1440W

Can this fitting be used with LEDs?

No

Can this fitting be used with a fan?

No

Can you install multiple time switches to control the same load?

Yes, the switches need to be wired in parallel

How do you adjust the time setting?

Adjust the rotary control as detailed within the installation instructions (in download tab)
