VECOBHEM3M
DISCONTINUED - Compact emergency LED bulkhead with ISO 7010 legend set
DISCONTINUED
White | 3.5W | 6300K | 200 lm | 30,000 hrs | IP65
VECOBHEM3M
DISCONTINUED
White | 3.5W | 6300K | 200 lm | 30,000 hrs | IP65
Features
- Polycarbonate construction
- 20mm gland entries as standard
- Minimum 3 hour functionality in emergency mode
- Facility for remote switching and non-maintained mode
- Dedicated self adhesive ISO 7010 format legend pack included with a combination of symbols: allows multiple exit path designation options
- Viewing distance 16m when used as an exit sign
- 210 lm when connected to mains,127 lm in emergency mode
- Battery: 3.6V Ni-Cad, 3 x C cells 1200mAH
- Replacement battery code: EB12
- M.O.M: 1 / O.P.Q: 20
Specification
| Lumens per watt | Up to 66 lm / W |
| Weight (kg) | |
| TSI Code | 406600334 |
Downloads
