WP42
Twin 4ft LED weatherproof batten
4ft | Twin | Grey | 38W | 4000K | 3880 lm | 40,000 hrs | IP65 | IK10
WP42
4ft | Twin | Grey | 38W | 4000K | 3880 lm | 40,000 hrs | IP65 | IK10
Features
This range is quick and easy to install due to “loop in & out” push fit connectors and features an IK10 “anti-drop” diffuser.
- Multiple cable entries, allowing for “loop in & out” wiring via push fit terminal block
- “Anti-drop” polycarbonate diffuser & gear tray for ease of installation
- Three mounting options – BESA box, directly onto ceiling surfaces or stainless steel suspension clips (included)
- IES files available for lighting designs
- Stainless steel diffuser clips supplied as standard, suitable for food industry applications
- Operating temperature: -20 to 45°C
- Supplied with a 20mm IP65 gland & fixings kit
- LED performance allows for “like for like” replacement of existing fluorescent luminaires
- Producing 102 lm / W
- IK10 rated fitting maximises durability and strength
- M.O.M: 1 / O.P.Q: 6
Specification
Lamp Specifications: | |
---|---|
Luminaire lumens (with diffuser) | 3880 lm |
Lumens from chip (no diffuser) | 4700 lm |
Useful lumens | 3800 lm |
Rated Wattage | 38W |
Rated luminous flux | 3800 lm |
Nominal life time of the lamp | 40,000 hrs |
Colour temperature | 4000K |
Number of switching cycles before premature lamp failure | ≥15,000 |
Warm-up time up to 60 % of the full light output | Instant full light |
Is this product dimmer compatible? | No |
Nominal beam angle | 120° |
Rated power wattage | 38W |
Rated lamp lifetime | 40,000 hrs |
Lamp power factor | >0.9 |
Lumen maintenance factor at end of nominal life | ≥0.70 |
Starting time | <0.1s |
Colour rendering | ≥80 Ra |
Colour consistency | Within a 6 step Macadam ellipse |
Rated peak intensity | 880cd |
Rated beam angle | 120° |
Voltage / Frequency | 240V~50Hz |
lm / w | 102 lm / W |
Not suitable for accent lighting |
