BATL5HOEM3

5FT high output LED batten

White | 60W | 4200K | 7550 lm | 35,000 hrs | IP20



         icon-led  icon-5year

BATL5HOEM3

White | 60W | 4200K | 7550 lm | 35,000 hrs | IP20



         icon-led  icon-5year

Categories: Battens - Interior, Emergency Lighting
SKU: 5013845057417
More Information
Features

Full photometric data available to enable lighting designs. Light output is equivalent or superior to traditional fluorescent battens

  • Pressed steel body and polycarbonate diffuser
  • LED tray can be removed from the housing for easy installation
  • 20mm knockout glands at each end for through wiring options
  • BESA box mounting
  • Gear tray retaining straps
  • Push terminal connections
  • LiFePO4 Lithium battery technology offering reduced energy consumption, enhanced charging cycle capacity & improved operational life compared to standard NiCad products
  • Built-in battery overcharge protection
  • 3 hour non maintained operation
  • Integrated green charging indicator LED
  • 160 lm in emergency mode
  • Battery – Li-Ion 3.2V 1500mAh
  • Battery 1 year warranty – Replacement battery code: EB19
  • M.O.M: 1 / O.P.Q: 6
Specification
Lamp Specifications:
Luminaire lumens (with diffuser) 7550 lm
Lumens from chip (no diffuser) 8700 lm
Useful lumens 7300 lm
Rated Wattage 60W
Rated luminous flux 7300 lm
Nominal life time of the lamp 35,000 hrs
Colour temperature 4200K
Number of switching cycles before premature lamp failure >15,000
Warm-up time up to 60 % of the full light output Instant full light
Is this product dimmer compatible? No
Nominal beam angle 120°
Rated power wattage 60W
Rated lamp lifetime 35,000 hrs
Lamp power factor >0.9
Lumen maintenance factor at end of nominal life ≥0.70
Starting time <0.1s
Colour rendering ≥80 Ra
Colour consistency Within a 6 step Macadam ellipse
Rated peak intensity 2418cd
Rated beam angle 120°
Voltage / Frequency 240V~50Hz
Lumens per watt 126 lm / W
Eathed
Not suitable for accent lighting
