7W LED bulkhead with 120° PIR

Black | 7W | 3100K | 500 lm | 35,000 hrs | IP44 | 120° PIR


icon-7w  icon-3100k  icon-500lm  icon-35000hrs  icon-ip44  icon-led  icon-120pir


Black | 7W | 3100K | 500 lm | 35,000 hrs | IP44 | 120° PIR


icon-7w  icon-3100k  icon-500lm  icon-35000hrs  icon-ip44  icon-led  icon-120pir

SKU: 5013845044578 Categories: ,
Categories: Ceiling/Wall/Bulkheads
SKU: 5013845044578
More Information

Energy efficient LED alternative to traditional bulkheads

Small robust bulkhead with PIR option that offers durability for domestic and light commercial applications


  • 7W, 500 Lumens, 35,000 hours average rated life
  • Tough polycarbonate construction
  • Time on adjustment 5 secs – 5 mins
  • Lux level adjustments
  • 120° detection angle
  • 8 metre detection range
  •  M.O.M: 1 / O.P.Q: 10
Lamp Specifications:
Lumens total flux 500 lm
Lumens 120° flux 450 lm
Rated Wattage 7W
Rated luminous flux 500 lm
Nominal life time of the lamp 35,000 hrs
Colour temperature 3100K
Number of switching cycles before premature lamp failure ≥15,000
Warm-up time up to 60 % of the full light output Instant full light
Is this product dimmer compatible? No
Nominal beam angle 120°
Rated power wattage 7W
Rated lamp lifetime 35,000 hrs
Lamp power factor >0.5
Lumen maintenance factor at end of nominal life ≥0.70
Starting time <0.1s
Colour rendering ≥80
Colour consistency Within a 6 step Macadam ellipse
Rated peak intensity 180cd
Rated beam angle 120°
Charger Output Voltage 240V
Lumens per watt Up to 71 lm / W
Weight (kg) 0.653
TSI Code 402080835
Not suitable for accent lighting

You will need Adobe Acrobat Reader to access and print PDFs.


Is there a troubleshooting guide?

For troubleshooting guide please refer to the installation instructions (in the download tab)

What adjustment controls are there?

Lux and time can be adjusted using the two rotary dials

What is the detection area?

120° – maximum 8m when installed at 2.5m height
