CFLWHEM3SC

17W LED emergency ceiling/wall light

White | 17W | 4000K | 1843 lm | 50,000 hrs | IP65





icon-led



CFLWHEM3SC

White | 17W | 4000K | 1843 lm | 50,000 hrs | IP65





icon-led



Categories: Ceiling/Wall/Bulkheads, Emergency Lighting
SKU: 5013845056038
More Information
Features
  • Polycarbonate construction
  • Visually similar, energy efficient alternative to 28W 2D fittings
  • Multiple low power LED array & optically optimised diffuser: ensures a soft lighting effect with no degredation of light output
  • 3hr maintained emergency lighting: also available in non-emergency options
  • Facility for non-maintained mode
  • Battery – LiFePO4 3.2V 1500mAh
  • Battery 5 year warranty -Replacement battery code: EB11
  • M.O.M: 1 / O.P.Q: 8
Specification
Lamp Specifications:
Luminaire lumens (with diffuser) 1843 lm
Lumens from chip (no diffuser) 2143 lm
Useful lumens 1668 lm
Rated Wattage 17W
Rated luminous flux 1668 lm
Nominal life time of the lamp 50,000 hrs
Colour temperature 4000K
Number of switching cycles before premature lamp failure ≥15,000
Warm-up time up to 60 % of the full light output Instant full light
Is this product dimmer compatible? No
Nominal beam angle 120°
Rated power wattage 17W
Rated lamp lifetime 50,000 hrs
Displacement factor ≥0.8
Lumen maintenance factor at end of nominal life ≥0.8
Starting time Instant full light
Colour rendering >80 Ra
Colour consistency Within a 6 step Macadam ellipse
Rated peak intensity 545cd
Rated beam angle 120°
Voltage / Frequency 240V~50Hz
Lumens per watt 98 lm / W
This product contains a Light Source of Energy Efficiency Class E
Not suitable for accent lighting
