MSLEDWHSC
17W LED ceiling/wall light with microwave sensor
White | 17W | 4000K | 1843 lm | 50,000 hrs | IP65
MSLEDWHSC
White | 17W | 4000K | 1843 lm | 50,000 hrs | IP65
Features
- Polycarbonate construction
- Visually similar, energy efficient alternative to 28W 2D fittings
- Multiple low power LED array & optically optimised diffuser: ensures a soft lighting effect with no degredation of light output
- M.O.M: 1 / O.P.Q: 8
Microwave sensor features:
- Adjustable detection angle: up to 150°
- Adjustable detection range: Max. 4-6m at 3m installation height
- Adjustable time setting: 5 seconds – 30 minute
- Adjustable Lux control: 2/10/25/50 lux or disable
- Detection is possible through doors, glass panels & thin walls
Specification
| Lamp Specifications: | |
|---|---|
| Luminaire lumens (with diffuser) | 1843 lm |
| Lumens from chip (no diffuser) | 2143 lm |
| Useful lumens | 1668 lm |
| Rated Wattage | 17W |
| Rated luminous flux | 1668 lm |
| Nominal life time of the lamp | 50,000 hrs |
| Colour temperature | 4000K |
| Number of switching cycles before premature lamp failure | ≥15,000 |
| Warm-up time up to 60 % of the full light output | Instant full light |
| Is this product dimmer compatible? | No |
| Nominal beam angle | 120° |
| Rated power wattage | 17W |
| Rated lamp lifetime | 50,000 hrs |
| Displacement factor | ≥0.8 |
| Lumen maintenance factor at end of nominal life | ≥0.8 |
| Starting time | Instant full light |
| Colour rendering | >80 Ra |
| Colour consistency | Within a 6 step Macadam ellipse |
| Rated peak intensity | 545cd |
| Rated beam angle | 120° |
| Voltage / Frequency | 240V~50Hz |
| Lumens per watt | 98 lm / W |
| This product contains a Light Source of Energy Efficiency Class E | |
| Not suitable for accent lighting | |
