HBAYLIN

150W Linear Highbay With 90° Lens

Black | 150W | 6300K | 21460 lm | 40,000 hrs | IP20



         icon-led  icon-5year

HBAYLIN

Black | 150W | 6300K | 21460 lm | 40,000 hrs | IP20



         icon-led  icon-5year

SKU: 5013845059275 Categories: , ,
Categories: High Bay & Low Bay, New Products
SKU: 5013845059275
More Information
Features

Long life, high performance luminaire offering low energy consumption and high lumen output at 143 lumens per watt. Ideal replacement for traditional HID metal halide fittings. For use in racked areas of warehouses or many other applications such as manufacturing, leisure facilities and retail environments.

  • Aluminium housing, polycarbonate lens cover
  • Supplied with 1.5m mains cable
  • Includes adjustable hanging kit (1.5m length)
  • Includes ceiling/wall tilt brackets
  • IES files available
  • 143lm/W
  • M.O.M: 1 / O.P.Q: 4
Specification
Lamp Specifications:
Luminaire lumens (with diffuser) 21460 lm
Lumens from chip (no diffuser) 22400 lm
Useful lumens 19300 lm
Rated Wattage 150W
Rated luminous flux 19300 lm
Nominal life time of the lamp 40,000 hrs
Colour temperature 6300K
Number of switching cycles before premature lamp failure ≥15,000
Warm-up time up to 60 % of the full light output Instant full light
Is this product dimmer compatible? No
Nominal beam angle 90°
Rated power wattage 150W
Rated lamp lifetime 40,000 hrs
Displacement factor 0.95
Lumen maintenance factor at end of nominal life ≥0.9
Starting time Instant full light
Colour rendering ≥80
Colour consistency Within a 6 step Macadam ellipse
Rated peak intensity 9859cd
Rated beam angle 90°
Voltage / Frequency 240V~50-60Hz
Lumen efficacy 143 lm / W
Not suitable for accent lighting
