KBAT6
6ft 32W LED economy batten fitting
- Pressed steel body and polycarbonate diffuser
- LED tray can be removed from the housing for easy installation
- 20mm knockout glands at each end for through wiring options
- BESA box mounting
- Gear tray retaining straps
- M.O.M: 1 / O.P.Q: 6
| Lamp Specifications: | |
|---|---|
| Luminaire lumens (with diffuser) | 3400 lm |
| Lumens from chip (no diffuser) | 4000 lm |
| Useful lumens | 3300 lm |
| Rated Wattage | 32W |
| Rated luminous flux | 3300 lm |
| Nominal life time of the lamp | 30,000 hrs |
| Colour temperature | 4000K |
| Number of switching cycles before premature lamp failure | 15,000 |
| Warm-up time up to 60 % of the full light output | Instant full light |
| Is this product dimmer compatible? | No |
| Nominal beam angle | 120° |
| Rated power wattage | 32W |
| Rated lamp lifetime | 30,000 hrs |
| Lamp power factor | >0.9 |
| Lumen maintenance factor at end of nominal life | >0.7 |
| Starting time | <0.5s |
| Colour rendering | >80 Ra |
| Colour consistency | Within a 6 step Macadam ellipse |
| Rated peak intensity | 702cd |
| Rated beam angle | 120° |
| Voltage / Frequency | 240V~50Hz |
| Lumens per watt | Up to 106 lm / W |
| Weight (kg) | 1.563 |
| TSI Code | 405435555 |
| Not suitable for accent lighting | |
