Stand alone internal 360° PIR sensor

White | IP20


icon-ip20  icon-360-pir


White | IP20


icon-ip20  icon-360-pir

SKU: 5013845036191 Categories: ,
Categories: Lighting Controls
SKU: 5013845036191
More Information
  • 1600W incandescent, 500W fluorescent load capacity
  • Max. 200W LED load capacity (no more than eight lights)
  • Adjustable lux level
  • Time on adjustable: 10 sec – 15 min
  • 4.5 metre radius range
  • 360° detection zone
  • M.O.M: 1 / O.P.Q: 50

You will need Adobe Acrobat Reader to access and print PDFs.


Can multiple SA360PIR be linked to control the same load?

We do not recommend using more than one PIR to control the same load

Does this PIR have a minimum load?


What is the maximum load?

1600W incandescent
500W fluorescent
200W LED (maximum eight lights)

What adjustment controls are there?

Lux and time can be adjusted. The controls can be found on the surface housing beneath the front cover

What is the detection area?

360° – approximate diameter of 5m when installed at 3m height
