RDT10A

External photoelectric switch

Grey | IP44



icon-ip44

RDT10A

Grey | IP44



icon-ip44
SKU: 5013845008839 Categories: ,
Categories: Lighting Controls
SKU: 5013845008839
More Information
Features
  • ABS construction
  • Switching level adjustable between approx. 5-300 lux
  • 10 Amp resistive, 3 Amp inductive load
  • Run back timer adjustable to stay on between 1-8 hours after switch on: flexibility in operation for economic running costs
  • Maximum 250W LED load capacity (no more than eight lights)
  • M.O.M: 1 / O.P.Q: 5
Specification
Weight (kg) 0.171
TSI Code 390011453
Downloads

You will need Adobe Acrobat Reader to access and print PDFs.

FAQ

Does this switch have a minimum load?

No

What is the maximum load?

10A / 2400W resistive load (incandescent)
3A / 720W inductive load (fluorescent)
250W LED (manximum ten lights)

What adjustment controls are there?

Lux and time can be adjusted in addtion to a ‘dusk-till-dawn’ setting

What are the on/off lux levels for the 'dusk-till-dawn' setting?

On at 20 lux, off at 70 lux
