VECOIFIRE3
Economy LED IP65 Fire Rated 3000K Dimmable Downlight
5W | 3000K | 540 lm | 36,000 hrs | IP65
VECOIFIRE3
5W | 3000K | 540 lm | 36,000 hrs | IP65
Features
PLEASE NOTE: due to the huge variety of dimmers in the market, dimming performance with all types cannot be guaranteed, compatibility should be tested before installation.
- Pressed steel construction
- Fire rated tested for individual 30, 60 and 90 min ceiling types
- Dimmable – for optimum dimming performance we recommend using a compatible LED dimmer
- Foam bezel seals against air permeability
- 60° beam angle
- Hole cut out dimension – 60mm
- Integrated chrome bezel with additional satin nickel and white bezels also included
- Push terminals
- Insulation bracket available separately – VECOIBRACK
- M.O.M: 1 / O.P.Q: 40
Specification
| Lamp Specifications: | |
|---|---|
| Luminaire lumens (with diffuser) | 540 lm |
| Lumens from chip (no diffuser) | 620 lm |
| Useful lumens | 510 lm |
| Rated Wattage | 5W |
| Rated luminous flux | 510 lm |
| Nominal life time of the lamp | 36,000 hrs |
| Colour temperature | 3000K |
| Number of switching cycles before premature lamp failure | 15,000 |
| Warm-up time up to 60 % of the full light output | Instant full light |
| Is this product dimmer compatible? | Yes |
| Nominal beam angle | 60° |
| Rated power wattage | 5W |
| Rated lamp lifetime | 36,000 hrs |
| Lamp power factor | >0.8 |
| Lumen maintenance factor at end of nominal life | ≥0.70 |
| Starting time | <0.1s |
| Colour rendering | ≥80 |
| Colour consistency | Within a 6 step Macadam ellipse |
| Rated peak intensity | 286cd |
| Rated beam angle | 60° |
| Voltage / Frequency | 240V~50Hz |
