VECORDL24

24W Economy recessed LED downlight

White | 24W | 4000K | 2400 lm | 25,000 hrs | IP20



         icon-led

VECORDL24

White | 24W | 4000K | 2400 lm | 25,000 hrs | IP20



         icon-led

SKU: 5013845054171 Categories: , ,
Categories: Downlights, Panels
SKU: 5013845054171
More Information
Features
  • Aluminium construction
  • Multiple low power LED array: even, shadow free diffused light output
  • Instant start to full illumination
  • Unobtrusive design with neutral white trim
  • Hole cut out size: 285mm
  • 4000K colour temperature: for neutral white appearance
  • M.O.M: 1 / O.P.Q: 20
Specification
Lamp Specifications:
Luminaire lumens (with diffuser) 2400 lm
Lumens from chip (no diffuser) 3120 lm
Useful lumens 2100 lm
Rated Wattage 24W
Rated luminous flux 2100 lm
Nominal life time of the lamp 25,000 hrs
Colour temperature 4000K
Number of switching cycles before premature lamp failure 15,000
Warm-up time up to 60 % of the full light output <0.5s
Is this product dimmer compatible? No
Nominal beam angle 115°
Rated power wattage 24W
Rated lamp lifetime 25,000 hrs
Lamp power factor >0.5
Lumen maintenance factor at end of nominal life >70%
Starting time <0.5s
Colour rendering ≥80 Ra
Colour consistency Within a 6 step Macadam ellipse
Rated peak intensity 543.27cd
Rated beam angle 115°
Voltage / Frequency 240V~50-60Hz
Lumens per watt
Weight (kg)
TSI Code 406600554
Not suitable for accent lighting
