WP61SDEM3
Single 6ft 10% step dim (corridor mode) emergency LED weatherproof fitting
Grey | 40W | 5000K | 4000 lm | 30,000 hrs | IP65
WP61SDEM3
Grey | 40W | 5000K | 4000 lm | 30,000 hrs | IP65
Superb one for one replacement for traditional fluorescent fixtures.
Robust range suitable for more open environments.
ROBUST FITTINGS SUITABLE FOR MULTIPLE OUTDOOR APPLICATIONS
Battery replacement service available. Click HERE for details.
- Polycarbonate housing and diffuser
- Multiple fixing options – supplied with surface mounting brackets and suspension hooks
- Gear tray retaining strap for easy installation
- IES files available
- Push-fit terminal block
- Stainless steel clips
- 100 lm / W
- Supplied with 20mm gland
- 3 hour duration maintained operation: facility for non-maintained mode or remote switching
- Replacement battery code: EB10/2
- M.O.M: 1 / O.P.Q: 6
STEP DIM (CORRIDOR MODE) MICROWAVE SENSOR FEATURES:
- Operation at 100% light level after last presence detection, reducing to standby dimming level selected after installer selected time delay
- Detection Area 10% / 50% / 75% / 100%
- Hold Time 5s / 30s / 1 min / 5 min / 10 min / 20 min / 30 min
- Stand By Period 0s / 10s / 1 min / 10 min / 30 min / 1hr / ∞
- Standby Dimming Level 10% / 20% / 30% / 50%
- Daylight Threshold 2 lux / 10 lux / 50 lux / Disable
- Detection Area – Max 14m (ceiling mount) Max 10m (wall mount)
- Detection is possible through doors, glass panels and thin walls
![](https://www.eterna-lighting.co.uk/wp-content/uploads/2016/12/wpled61_dim.jpg)
![](https://www.eterna-lighting.co.uk/wp-content/uploads/2023/02/ri-110px-replace-led-light-source-pro-e1676633947412.jpg)
![](https://www.eterna-lighting.co.uk/wp-content/uploads/2023/02/ri-110px-replace-control-gear-pro-e1676633971648.jpg)
Lamp Specifications: | |
---|---|
Luminaire lumens (with diffuser) | 4000 lm |
Lumens from chip (no diffuser) | 4800 lm |
Rated Wattage | 40W |
Rated luminous flux | 4000 lm |
Nominal life time of the lamp | 30,000 hrs |
Colour temperature | 5000K |
Number of switching cycles before premature lamp failure | ≥15,000 |
Warm-up time up to 60 % of the full light output | Instant full light |
Is this product dimmer compatible? | No |
Nominal beam angle | 120° |
Rated power wattage | 40W |
Rated lamp lifetime | 30,000 hrs |
Lamp power factor | 0.9 |
Lumen maintenance factor at end of nominal life | >70% |
Starting time | <0.5s |
Colour rendering | 80 Ra |
Colour consistency | Within a 6 step Macadam ellipse |
Rated peak intensity | 1425cd |
Rated beam angle | 120° |
Voltage | 240V |
Lumens per watt | |
Weight (kg) | |
TSI Code | 406600619 |
Not suitable for accent lighting |
