KFIRE4WH
5W LED IP65 Fire Rated IP65 Dimmable Downlight
White | 5W | 4000K | 515 lm | 25,000 hrs | IP65 (front) / IP20 (rear)
KFIRE4WH
White | 5W | 4000K | 515 lm | 25,000 hrs | IP65 (front) / IP20 (rear)
Features
Compact and convenient design with high quality loop in, loop out terminal block.
- Fire Rated – individually tested within 30, 60 and 90 minute ceiling constructions
- Dimmable – a compatible LED dimmer is recommended for optimum dimming performance
- Foam bezel seals against air permeability
- Compact and convenient design
- 40° beam angle
- Push terminals
- Loop-in Loop-out wiring facility
- M.O.M: 1 / O.P.Q: 20
Specification
| Lamp Specifications: | |
|---|---|
| Luminaire lumens (with diffuser) | 515 lm |
| Lumens from chip (no diffuser) | 600 lm |
| Useful lumens | 420 lm |
| Rated Wattage | 5W |
| Rated luminous flux | 420 lm |
| Nominal life time of the lamp | 25,000 hrs |
| Colour temperature | 4000K |
| Number of switching cycles before premature lamp failure | 12,500 |
| Warm-up time up to 60 % of the full light output | Instant full light |
| Is this product dimmer compatible? | Yes |
| Nominal beam angle | 40° |
| Rated power wattage | 5W |
| Rated lamp lifetime | 25,000 hrs |
| Lamp power factor | 0.8 |
| Lumen maintenance factor at end of nominal life | 70% |
| Starting time | <0.5s |
| Colour rendering | 80 |
| Colour consistency | Within a 6 step Macadam ellipse |
| Rated peak intensity | 649cd |
| Rated beam angle | 40° |
| Voltage / Frequency | 240V~50Hz |
Downloads
FAQ
What are the ceiling constructions?
30 and 60 min ceiling constructions with I-Joists
